SmartGate Conveyors

Are you always shoveling to load your wheel barrow?

Effortlessly unload your landscape materials with a SmartGate Conveyor.

No more back-breaking shoveling.

• MULCH• STONE• SOIL

Remote Controlled

No Towing Interference

For Many Materials

Replace your tailgate with a SmartGate - no retrofitting to most dump bodies.
Haul your product to the job while pulling your trailer of tools!
No need to attach and detach for every job.
Can be installed on electric over hydraulic, or fully hydraulic dump trucks

Does not hinder bulk deliveries
Unloads out either side
Eliminates one laborer
All functions remote controlled
Can be hand-lifted
Attaches/detaches in minutes
Designed and fabricated in the U.S

sgc

2086
2092

Side Discharge Model

Replace your tailgate with a SmartGate―no retrofitting to most dump bodies.
Haul your product to the job while pulling your trailer of tools!
Does the work of 1-2 laborers with no need to attach and detach for every job.
Does not hinder bulk deliveries
Unloads out either side
All functions remote controlled
Designed and built in the U.S.A.

Side Discharge Model ►

sgi

2035
2047

Incline Attachment

Increases clearance by 10-14”
Can be used for either side dispensing
Plumbs into existing SmartGate Conveyor Hydraulics
Can be added to existing SGC-20 cross conveyor anytime
Extends reach 26-36” from edge of SGC-20
Slides out for raised end to be hand-lifted into position
Stows on SGC-20 when not in use and during transport
Designed and built in the U.S.A.

Incline Attachment ►

sgs

4191

Rear Discharge Model

Can be installed on electric over hydraulic systems or PTO systems
Attaches to tailgate pivot brackets and chain pockets
Fast and accessible rear discharge
Does not hinder regular dump off
Inclines the material to allow for more clearance
All functions remote controlled
Handles a variety of materials… mulch, sand, stone, topsoil, and compost
Designed, manufactured, and assembled in the USA

Rear Discharge Model ►

sgd

3860

Dump Trailer Model

12’ and 14’ Dump Trailer and SmartGate setups available.
Unit will attach to most 7’ wide by 12’ or 14’ long dump trailers.
The unit is hinged and swings out of the way for normal dump off or equipment loading.
12 volt electric over hydraulic or auxiliary engine hydraulic power options.
All functions remote controlled.
Handles a variety of landscape materials… mulch, sand, stone, topsoil, and compost.
Designed, manufactured, and assembled in the USA.

Dump Trailer Model ►

SBK

Smart-Barrow Kit

Installs in 10 - 20 minutes
Fits most wood handled wheelbarrows
Adds an additional 3lbs
Using Milwaukee or DeWalt batteries
Two 9amp batteries can last several days
Motor life expectancy exceeds 3,000 hours
1 year warranty
Wheelbarrow and Batteries not included

Smart-Barrow Kit ►

SmartGate Series Dump Trailers

SmartGate Series
Dump Trailers

DT

716

SmartGate Series 16’ Dump Trailer

21’ Overall Length
16’ Long Frame with 55 ½” Long A Frame Tongue (from front edge of dumpbox to center of ball pivot)
16’ Long x 81 ¾” Wide (inside wall to wall) Dump Trailer Area, 28 ½” off Ground
14,000lb GVWR (Tandem – 7,000lb Spring Axles)
235/80R16 LRG Tires, Spare Tire Mount, and Electric Wheel Brakes
12,000lb Electric/Hydraulic Jack
8” Tube Steel Frame
7 Gauge One Piece Dump Floor with 24” High 10 Gauge Sides
14 Gauge Diamond Plate Fenders
72” Under Dump Area Slide Out Aluminum Ramps
LED Sealed Lights with Rubber Grommets (Integrated Reverse Lights in Brake Lights)
7 RV Plug and 2 Gauge Wire with 175amp Grey Plug for Battery Charging from Tow Vehicle
9 Ton Scissor Lift Hoist with 50 degree Dump and Power Up and Power Down
Recessed A Frame Lockable Tool Box
Manual Tarp Kit and Adjustable 2 5/16th Ball Receiver
Sand Blasted Surface Prep, Primed, and Powder Coating Finish
5 Year Spring Axle Warranty and 1 Year Manufacturer’s Warranty (non-wearable parts)

PDT

7412

SmartGate Series Platform/Dump Trailer

21’ 6" Overall Length
16’ Long Frame with 55 ½” Long A Frame Tongue (from front edge of platform to center of ball pivot)
12’ Long x 81 ¾” Wide (inside wall to wall) Dump Trailer Area, 28 ½” off Ground
54” x 81” Platform Deck, 22 ½” off Ground with Heavy Duty Grate Flooring and 6” High Side Rails
66” Long Passengers Side Ramp Gate with 1,500lb per Axle Weight Capacity Rating
14,000lb GVWR (Tandem – 7,000lb Spring Axles)
235/80R16 LRG Tires, Spare Tire Mount (no tire), and Electric Wheel Brakes
12,000lb Electric/Hydraulic Jack
8” Tube Steel Frame
7 Gauge One Piece Dump Floor with 24” High 11 Gauge Sides
14 Gauge Diamond Plate Fenders
72” Under Dump Area Slide Out Aluminum Ramps
LED Sealed Lights with Rubber Grommets (Integrated Reverse Lights in Brake Lights)
7 RV Plug and 2 Gauge Wire with 175amp Grey Plug for Battery Charging from Tow Vehicle
8.5 Ton Scissor Lift Hoist with 55 degree Dump Angle and Power Up and Power Down
Recessed A Frame Lockable Tool Box
Manual Tarp Kit and Adjustable 2 5/16th Ball Receiver
Sand Blasted Surface Prep, Primed, and Powder Coating Finish
5 Year Spring Axle Warranty and 1 Year Manufacturer’s Warranty (non-wearable parts)

TDT

7214

SmartGate Series Toolbox Dump Trailer

21’ Overall Length
16’ Long Frame with 55 ½” Long A Frame Tongue (from front edge of toolbox to center of ball pivot)
14’ Long x 81 ¾” Wide (inside wall to wall) Dump Trailer Area, 28 ½” off Ground
24” Deep x 84” Long x 54” High Toolbox with 32” High Aluminum Door and Gas Shocks
3 Rows of E-Track Adjustable Rails
14,000lb GVWR (Tandem – 7,000lb Spring Axles
235/80R16 LRG Tires, Spare Tire Mount, and Electric Wheel Brakes
12,000lb Electric/Hydraulic Jack
8” Tube Steel Frame
7 Gauge One Piece Dump Floor with 24” High 11 Gauge Sides
14 Gauge Diamond Plate Fenders
72” Under Dump Area Slide Out Aluminum Ramps
LED Sealed Lights with Rubber Grommets (Integrated Reverse Lights in Brake Lights)
7 RV Plug and 2 Gauge Wire with 175amp Grey Plug for Battery Charging from Tow Vehicle
9 Ton Scissor Lift Hoist with 50 degree Dump and Power Up and Power Down
Recessed A Frame Lockable Tool Box
Manual Tarp Kit and Adjustable 2 5/16th Ball Receiver
Sand Blasted Surface Prep, Primed, and Powder Coating Finish
5 Year Spring Axle Warranty and 1 Year Manufacturer’s Warranty (non-wearable parts)

Power Components

We used our SmartGate Conveyor first to unload wet loam off the truck to repair snow plowing damage along driveway and parking lot areas. The guys loved it. We have been using it for about a month now for mulch and it’s savings dividends! With not having to get up into the truck, it saves time, energy, and better overall efficiency for loading wheel barrows! The guys are very happy with the purchase!

Derek at Make a Difference Landscaping, NH

"These units are user friendly. Absolutely eliminates back breaking labor and one worker on the job. Wheelbarrow loads in 6 seconds. Either side discharge is very useful. We love it for stone. Saves time and money!"

Steve
Cutting Edge Lawn Care

"SmartGate saved us a guy on the job! It's a great tool and a great buy!"

Josh
Scottville, MI

"It definitely saved 1-2 guys on our crew. We didn't care to do decorative gravel jobs before because it was so hard to handle but now with the SmartGate Conveyor, we don't mind them at all!"

Steve
Oswego, IL

FAQ

What all material can you use?

Any loose, bulk material like mulch, stone, soil, sand, etc, are able to be handled. Large stones or boulders should not be handled as that can damage the unit. The SmartGate replaces your standard tailgate and functions as a side unload conveyor on your tailgate as you dump the bed. When handling brush and debris, the dump bed can be used like normal.

What truck beds does this fit?

The SmartGate fits on most standard dump bodies. Contact us for custom installation.

Can I still use the dump and hitch on the truck?

Yes, the SmartGate Conveyor is slightly larger than a standard dump tailgate. It does not interfere with hitch or dump bed usage.

What are the maintenance points?

The SmartGate unit requires little maintenance. A few grease points and regular hydraulic maintenance will keep your unit running smoothly. After several weeks of use, the conveyor belt may need tightening and after several years may require replacement. The cables that open and close the unit should be observed for wear and may require replacement yearly.

How easy is the SmartGate Conveyor to install?

The SmartGate unit attaches to a standard dump body on the bottom dump latches and the open/close cables attach to the side of the truck bed. No extra bolting or brackets are required. That SmartGate is powered by the electric or hydraulic dump power. The unit itself weighs about 300 lbs. If you no longer need the SmartGate or need to switch between trucks, it is a simple switch over. Simple unlatch, unhook the cables and hoses and remove the unit.
